The claw-shaped design of this anchor is both functional and innovative. The claws dig into the seabed, creating a secure and stable connection that prevents the boat from drifting.
• Constructed from hot dipped galvanized steel. it shares all of the features associated with the original claw/bruce anchor. recommended for boat length up to 14 ft
• Excellent holding power in nearly all seafloor including mud, sand, rock, and coral. one of the easiest anchors to both set and recover.
• This claw anchor can be used with a variety of bow roller styles to make dropping, weighing and storing easy
• Durable, corrosion-resistant hot-dipped galvanized steel construction
H.D.G Claw Anchor
| Part No | Weight(kg) | Dimemslons(mm) | ||||||||
| - | - | A | B | c | D | E | F | Hole | Hole | |
| DTA036 | 1 | 176 | 295 | 142 | 7 | 90 | 110 | 19*8 | φ7 | |
| DTA037 | 2 | 215 | 340 | 195 | 10 | 95 | 130 | 22*11 | φ7 | |
| DTA038 | 5 | 280 | 485 | 298 | 12 | 165 | 198 | 25*13 | 9 | |
| DTA039 | 7.5 | 318 | 518 | 340 | 13 | 180 | 205 | 28*13 | φ11 | |
| DTA040 | 10 | 340 | 580 | 358 | 16 | 190 | 250 | 19*13 | φ12 | |
| DTA041 | 15 | 380 | 615 | 400 | 16 | 230 | 240 | 30*15 | φ10 | |
| DTA042 | 20 | 410 | 642 | 460 | 22 | 255 | 270 | 38*18 | φ15 | |
| DTA043 | 30 | 460 | 810 | 535 | 22 | 275 | 290 | 42*20 | φ13 | |
| DTA044 | 50 | 575 | 860 | 710 | 30 | 320 | 385 | 50*22 | φ18 | |
